Detail Photos of Zenith
Aircraft Company's new demo ZODIAC XL, powered by the 100-hp
Rotax 912S. |
|
 |
Rotax 912S engine installation. |
 |
Rotax 912S engine installation. Notice the prop extension for the new cowl. |
 |
A view from the top of the Zodiac cabin. |
 |
The ZODIAC XL instrument panel |
 |
Inside the ZODIAC XL |
 |
Aileron trim tab (left wing). |
 |
Elevator trim tab (left side). |
 |
Flush-mounted fuel cap (left wing). |
 |
Landing / taxi lights (left wing). |
 |
White tail light. |
 |
The closed canopy. |
- Click here for detailed construction photos
