ZODIAC XL: WINGS SECTION

ZODIAC XL Wing Assembly

  ZODIAC XL Wings & Aileron Kit and Parts

The following parts are included in the Wings Kit.  Click the box on the left of the part number to select the part. Click the Quote / Order Selected Parts button on the bottom of the page to add all selected parts to your shopping cart. Click the part number to view an illustration / details about the part. Enter the desired quantity in the shopping cart.

ZODIAC CH 601 Series - WING PARTS:
Part Number Part Description (click for illustration) Required Quantity Unit Price Inventory Code
6W1-1L LEFT FLAP RIB 6 $9.10 A
6W1-1R RIGHT FLAP RIB 6 $9.10 A
6W1-2L LEFT FLAP SKIN 1 $84.10 A
6W1-2R RIGHT FLAP SKIN 1 $84.10 A
6W1-3 CONTROL PLATE 2 $5.10 A
6W1-4 PIANO HINGE 7ft (MS20257-4) 2 $25.10 A
6W2-1 AILERON HORN 2 $4.60 A
6W2-2L LEFT AILERON RIB 3 $8.92 A
6W2-2R RIGHT AILERON RIB 3 $8.92 A
6W2-3L LEFT AILERON SKIN 1 $85.20 A
6W2-3R RIGHT AILERON SKIN 1 $85.20 A
6W2-4L LEFT AILERON TIP 1 $12.60 A
6W2-4R RIGHT AILERON TIP 1 $12.60 A
6W3-4 w/6W5-1 COMPLETE SPAR ASSEMBLY w/CENTER SECTION 1 $2,145.00 A
6W5-1L LEFT SPAR TIP 1 $16.00 A
6W5-1R RIGHT SPAR TIP 1 $16.00 A
6W5-2L LEFT NOSE RIB 8 $28.80 A
6W5-2R RIGHT NOSE RIB 8 $28.80 A
6W6-1L LEFT REAR RIB #1 1 $33.50 A
6W6-1R RIGHT REAR RIB #1 1 $33.50 A
6W6-2L LEFT REAR RIB #2 1 $36.00 A
6W6-2R RIGHT REAR RIB #2 1 $36.00 A
6W6-3L LEFT REAR RIB #3 1 $37.00 A
6W6-3R RIGHT REAR RIB #3 1 $37.00 A
6W6-4L LEFT REAR RIB #4 1 $38.00 A
6W6-4R RIGHT REAR RIB #4 1 $38.00 A
6W6-5L LEFT REAR RIB #5 1 $38.50 A
6W6-5R RIGHT REAR RIB #5 1 $38.50 A
6W6-6L LEFT REAR RIB #6 1 $38.50 A
6W6-6R RIGHT REAR RIB #6 1 $38.50 A
6W6-7L LEFT REAR RIB #7 1 $39.00 A
6W6-7R RIGHT REAR RIB #7 1 $39.00 A
6W6-8L LEFT REAR RIB #8 1 $39.50 A
6W6-8R RIGHT REAR RIB #8 1 $39.50 A
6W6-9LLEFT REAR RIB #91$40.00A
6W6-9RRIGHT REAR RIB #91$40.00A
6W6-10BELLCRANK SUPPORT CHANNEL2$8.10A
6W6-11BELLCRANK SUPPORT4$4.00A
6W7-1iLLEFT INBOARD REAR CHANNEL1$75.00A
6W7-1RRIGHT INBOARD REAR CHANNEL1$75.00A
6W7-1iLLEFT OUTBOARD REAR CHANNEL1$75.00A
6W7-1RRIGHT OUTBOARD REAR CHANNEL1$75.00A
6W7-2ROOT DOUBLER2$5.00A
6W7-3HINGE DOUBLER2$5.80A
6W8-1LLEFT LEADING EDGE SKIN1$117.00A
6W8-1RRIGHT LEADING EDGE SKIN1$117.00A
6W8-2REAR BOTTOM SKIN2$90.00A
6W8-3REAR TOP SKIN2$90.00A
6W9-1TIEDOWN RING2$9.20A
6W9-2PITOT/STATIC TUBE 1/4” OD ASSEMBLY w/FFLT-64 (2-6”)1$61.00A
6W9-3BELLCRANK ACCESS COVER2$4.00A
6W9-4WING TIP SHEET2$8.00A
6W9-5LLEFT FIBERGLASS WINGTIP1$75.40A
6W9-5RRIGHT FIBERGLASS WINGTIP1$75.40A
6W9-6WINGTIP BOTTOM ANGLE3$7.10A
6W9-7WINGTIP TOP ANGLE3$7.10A
6W10-1AILERON BELLCRANK w/6W10-2 SPACERS2$38.10A
6W10-3BUSHING diam ¼”x.028”2$3.90A
6W10-4AILERON STOP2$4.00A
6W10-5THREADED STEEL ROD 5/16x230mm2$7.10A
6W11-19AILERON ROD HOLE DOUBLER2

$25.00

A
CW-5-125/16” ROD ENDS4$8.00A
AN316-5R5/16" JAM NUT4$0.29A
AN5-15ASPAR BOLT12$0.65A
AN960-516WASHER12$0.08A
AN365-524NYLOK NUT12$0.45A
AN3-12ABELLCRANK BOLT2$0.55A
AN960-10WASHER4$0.04A
AN365-1032NYLOK NUT2$0.15A
F487-4PITOT STATIC POLY TUBE ¼” OD (24ft)1$19.44A
LSTANDARD L ANGLES 4ft6$7.10A
A41/8” RIVETS1000$0.08A
A55/32” RIVETS2000$0.09A
78 deg PLATE78 DEGREE STEEL PLATE1$7.10A
CRIMPHAND CRIMPER1$21.30A
