ZODIAC CH 650: Wings Section

ZODIAC Ch 650 Wings & Aileron Kit and Parts

Click here to quote/order the complete Wings Kit.
Illustrated Parts Catalog:
Click here for ZODIAC CH 650 wings design info
Click here for the Fuel System kit

The following parts are included in the Wings Kit. Click the box on the left of the part number to select the part. Click the Quote / Order Selected Parts button on the bottom of the page to add all selected parts to your shopping cart. Click the part number to view an illustration / details about the part. Enter the desired quantity in the shopping cart.

ZODIAC CH 650 - Wing Parts:
Part Number	Part Description (click for illustration)	Required Quantity	Unit Price	Inventory Code
6W1-1L	LEFT FLAP RIB	6	$9.10	A
6W1-1R	RIGHT FLAP RIB	6	$9.10	A
6W1-2L	LEFT FLAP SKIN	1	$84.10	A
6W1-2R	RIGHT FLAP SKIN	1	$84.10	A
6W1-3	CONTROL PLATE	2	$5.10	A
6W1-4	PIANO HINGE 7ft (MS20257-4)	2	$25.10	A
6W2-1	AILERON HORN	2	$4.60	A
6W2-2L	LEFT AILERON RIB	5	$8.92	A
6W2-2R	RIGHT AILERON RIB	5	$8.92	A
6W2-3L	LEFT AILERON SKIN	1	$85.20	A
6W2-3R	RIGHT AILERON SKIN	1	$85.20	A
6W2-4L	LEFT AILERON TIP	1	$12.60	A
6W2-4R	RIGHT AILERON TIP	1	$12.60	A
65W2-5	AILERON RIB #2 GUSSET	2	$8.25	A
65W2-6	AILERON RIB #1 GUSSET	2	$7.75	A
6W3 w/ 6W4	COMPLETE SPAR ASSEMBLY w/CENTER SECTION	1	$2,145.00	A
6W5-1L	LEFT SPAR TIP	1	$16.00	A
6W5-1R	RIGHT SPAR TIP	1	$16.00	A
6W5-2L	LEFT NOSE RIB	7	$28.80	A
6W5-2R	RIGHT NOSE RIB	7	$28.80	A
6W6-1L	LEFT REAR RIB #1	1	$33.50	A
6W6-1R	RIGHT REAR RIB #1	1	$33.50	A
6W6-2L	LEFT REAR RIB #2	1	$36.00	A
6W6-2R	RIGHT REAR RIB #2	1	$36.00	A
6W6-3L	LEFT REAR RIB #3	1	$37.00	A
6W6-3R	RIGHT REAR RIB #3	1	$37.00	A
6W6-4L	LEFT REAR RIB #4	1	$38.00	A
6W6-4R	RIGHT REAR RIB #4	1	$38.00	A
6W6-5L	LEFT REAR RIB #5	1	$38.50	A
6W6-5R	RIGHT REAR RIB #5	1	$38.50	A
6W6-6L	LEFT REAR RIB #6	1	$38.50	A
6W6-6R	RIGHT REAR RIB #6	1	$38.50	A
6W6-7L	LEFT REAR RIB #7	1	$39.00	A
6W6-7R	RIGHT REAR RIB #7	1	$39.00	A
6W6-8L	LEFT REAR RIB #8	1	$39.50	A
6W6-8R	RIGHT REAR RIB #8	1	$39.50	A
6W6-9L	LEFT REAR RIB #9	1	$40.00	A
6W6-9R	RIGHT REAR RIB #9	1	$40.00	A
6W6-10	BELLCRANK SUPPORT CHANNEL	2	$8.10	A
6W6-11	AILERON BELLCRANK SUPPORT	4	$4.00	A
6W7-1iL	LEFT INBOARD REAR CHANNEL	1	$75.00	A
6W7-1R	RIGHT INBOARD REAR CHANNEL	1	$75.00	A
6W7-1iL	LEFT OUTBOARD REAR CHANNEL	1	$75.00	A
6W7-1R	RIGHT OUTBOARD REAR CHANNEL	1	$75.00	A
6W7-2	ROOT DOUBLER	2	$5.00	A
6W7-3	HINGE DOUBLER	2	$5.80	A
6W8-1L	LEFT LEADING EDGE SKIN	1	$117.00	A
6W8-1R	RIGHT LEADING EDGE SKIN	1	$117.00	A
6W8-2	REAR BOTTOM SKIN	2	$90.00	A
6W8-3	REAR TOP SKIN	2	$90.00	A
6W9-1	TIEDOWN RING	2	$9.20	A
6W9-2	PITOT/STATIC TUBE 1/4" OD ASSEMBLY w/FFLT-64(2-6")	1	$61.00	A
6W9-3	BELLCRANK ACCESS COVER	2	$4.00	A
65W9-5L	LEFT FIBERGLASS WING TIP	1	$75.40	A
65W9-5R	RIGHT FIBERGLASS WING TIP	1	$75.40	A
6W10-1	AILERON BELLCRANK w/6W10-2 SPACERS	2	$38.10	A
6W10-3	BUSHING dia 1/4" x 0.028"	2	$3.90	A
6W10-4	AILERON STOP	2	$4.00	A
6W10-5	THREADED STEEL ROD 5/16" x 230mm	2	$7.10	A
6W11-19	AILERON ROD HOLE DOUBLER	2	$25.00	A
65W12-1	BALANCE ARM	2	$6.00	A
65W12-2	BALANCE WEIGHT SHIM	6	$3.00	A
65W12-3	BALANCE WEIGHT	24	$3.00	A
ZODIAC CH 650 - Parts Included in Complete Spar Assembly:
65W3-1	WING SPAR WEB	2	$65.00	A
65W4-1	FRONT CENTER SPAR WEB	1	$105.00	A
65W4-2	REAR CENTER SPAR WEB	1	$85.00	A
6W4-3	CENTER SPAR CAP	4	$31.15	A
6W4-4	UPRIGHTS	10	$8.00	A
6W4-5	SPACER	10	$4.00	A
6W4-6	UPRIGHT SHIMS	10	$2.00	A
65W11-1	WING ROOT DOUBLER	2	$22.50	A
65W11-2	FRONT UPPER SPAR DOUBLER	2	$45.15	A
65W11-3	FRONT LOWER SPAR DOUBLER	2	$45.60	A
65W11-4	REAR UPPER SPAR CAP	2	$95.35	A
65W11-5	REAR LOWER SPAR CAP	2	$95.80	A
65W11-6	TOP O/B SPAR CAP ANGLE	2	$41.80	A
65W11-8	HAT STIFFENERS	6	$18.00	A
65W11-9	EXTRUSION ANGLE	2	$25.00	A
65W11-10	BOTTOM I/B SPAR CAP ANGLE	2	$53.70	A
65W11-11	NOSE RIB ANGLE	10	$6.50	A
65W11-12	TOP DOUBLER	1	$15.50	A
65W11-13	FRONT BOTTOM ANGLE	1	$13.00	A
65W11-14	NOSE RIB ANGLE	4	$6.50	A
65W11-15	SEAT FRONT ANGLE	1	$12.00	A
65W11-16	REAR BOTTOM ANGLE	1	$13.00	A
65W11-17	RIB ANGLE	6	$6.50	A
65W11-18	REAR CHANNEL DOUBLER	2	$7.00	A
65W11-19	AILERON ROD HOLE DOUBLER	2	$7.00	A
65W11-20	CHANNEL ANGLE	2	$7.00	A
ZODIAC CH 650 - Wing Hardware:
CW-5-12	5/16" ROD ENDS	4	$8.00	A
AN316-5R	5/16" JAM NUT	4	$0.29	A
NAS6605-22	5/16" NAS BOLT	8	$1.40	A
NAS6605-23	5/16" NAS BOLT	4	$1.75	A
AN525-10R7	MACHINE WASHER SCREW	16	$0.25	A
MS21075-L3	3/16" FLOATING NUT PLATE	16	$1.05	A
AN960-516	WASHER	12	$0.08	A
AN365-524	NYLOK NUT	12	$0.45	A
AN3-11A	3/16" BOLT	6	$0.75	A
AN3-12A	3/16" BOLT	2	$0.75	A
AN3-30A	3/16" BOLT	4	$0.42	A
AN960-10	WASHER	12	$0.04	A
AN365-1032	NYLOK NUT	12	$0.15	A
F487-4	PITOT STATIC POLY TUBE 1/4" OD (24ft)	1	$19.44	A
L	STANDARD L ANGLES 4ft	28	$7.10	A
A3	3/32� RIVETS	32	$0.08	A
A4	1/8� RIVETS	1300	$0.08	A
A5	5/32� RIVETS	2220	$0.09	A
